Description
Amplifier Power Transformer T29260T/2
This Power Transformer is part of a specialist range of transformers for use with SINGLE ENDED and PUSH-PULL valve amplifiers.
- MAINS Transformer
- MODEL: T29260T/2
- Power Transformer designed for Valve Amplifiers
- Mounting:
- INPUT: 230V / 240V
- For 240V input connect mains across terminals 17-13
- For 230V operation connect mains across terminals 15-13
- Insulate all unused terminals
- Magnetising current @ 240V = 80mA (nominal)
- Offload voltages
- OUTPUT 1: 278V +/-2V
- OUTPUT 2: 6.95V +/-2V
- OUTPUT 3: 21.4V +/-2V
- Core Materials: Manufactured with grain orientated silicon steel laminations for reduced hum, low distortion, low insertion loss and stray field.
- Mass: 2.63kg
- Brand: Oxford Electrical Products (CARNHILL GROUP)
- Made in OXFORD, ENGLAND (UK)
Oxford Electrical Products (OEP) was founded in 1982, and has established itself as a globally trusted brand for the design and manufacture of transformers and power supplies.
The Amplifier Power Transformer T29260T/2 is part of a specialist range of audio transformers for valve amplifiers, that are designed and manufactured from OEP’s factory in Oxford, England. This design and manufacturing expertise enables OEP to maintain a close control over production, ensuring that each transformer is manufactured to the strict specifications that their designer intended. This build quality directly governs the efficiency of the transformer for excellent sound quality and reliability.
